Basic Specifications
Certification
ECE, GCC, CE, DOT, CCC, ISO/TS16949
Detailed Technical Specifications
|
| Length | 14000(13900)mm |
| Width | 2550(2450)mm |
| Height | 4000(2700)mm |
|
| Height | 400mm (low temperature resistance 700K2) |
| Ventral plate | 6# |
|
| Base plate | Bamboo glue board-28# thick with seam sealer |
| Tool box | Aluminium alloy (1.5m x 0.6m x 0.5m) |
| ABS | WABCO warning light fitted |
| Traction Pins | JOST 50# Live Pins |
| Axle | 1840 triple axle 13T disc brake |
| Tyres | Triangle 385/65R22.5 (7 sets) |
| Suspension | Air suspension (6 airbags, front axle lift) |
Key Product Advantages
1. Structural Integrity
Unique overall camber structure of the longitudinal beam ensures lifetime downward bending-free performance and fuel efficiency.
2. Sophisticated Manufacturing
Fabricated using automatic tracking submerged arc welding and high-precision distance measuring equipment.
3. Advanced Suspension
Features balanced load distribution across axles and optimized tie rod angles to minimize tire wear.
4. Safety Systems
Equipped with optional high-quality ABS to prevent side slip and drifting during emergency braking.
5. Humanized Design
Includes safety features like spin lock limiters and three-way valves for improved parking brake safety.
Frequently Asked Questions
What is the load capacity of this semi-trailer?
The LC9400 model has a rated load capacity of 50T and a total mass capacity of 60T.
What type of suspension is used?
This trailer utilizes an air suspension system with 6 airbags and includes a front axle lift function.
Is the braking system equipped with ABS?
Yes, it features a WABCO ABS Anti-lock Braking System with a fitted warning light for enhanced safety.
What materials are used in the construction?
The trailer is constructed using high-quality aluminum and features a 28# thick bamboo glue base plate.
What certifications does the vehicle have?
The vehicle is certified under ECE, GCC, CE, DOT, CCC, and ISO/TS16949 standards.
What is the painting process for the trailer?
The trailer undergoes a professional baking varnish process, including two layers of primer and two layers of top coat.
